PCB POPULATION AND MOUNTING

1. Pigtailed elements – fixed PCBs (multi- layer PCBs as well)

Services

zvětšit obrázek

Forming elements
    Axial pigtails
    Radial pigtailsElement population
    Mounting Soldering process (both leadless and leaded)
    Wave
    Manual soldering
Limitation

Special fixturing (in bulk) Automaton (strip) Max. width 300 mm, length 500 mm

Optimum series

as per customer requirement


2. SMD elements – fixed (also multi-layer ones)

zvětšit obrázek

Services

Soldering paste application
    Mechanical
    Manual fixturingAdhesive application
    dtto Element population
    SMT automaton
    Creating population software both by conversion from the data and by     reading background papers
    Manual and servicing workplace Soldering process
    Melting furnaces
    Soldering wave
    Manual soldering

Limitation

Maximum dimension paste
    250 x 300 mm Maximum size for population
    300 x 450 mm manual
    200 x 300 mm mechanical Maximum soldering width
    300 mm PCB

Optimum batch

Recommended one-shot up to 3000 pcRepeated from 300 pc

3. Additional mounting – screwing, riveting, cabling

zvětšit obrázek

Services

Mounting according to technological processes Testing the entire completed assemblies

4. Production inspection

Services

Statistic process inspection100% check – as per working process100% functional testsStatistical final inspection
